Digital Scale Indicator ENQUIRE NOW BUY NOW
RIR300
- legal for trade use (MCA # 1736)
- trade approval applies when this indicator is connected to approved weighing bases
- single or dual range
- ABS plastic housing with IP65 rating
- 20mm LCD display with green LED backlight for clear visibility
- 2 setpoint outputs (300mA max)
- comes loaded with K356 firmware
- 1 programmable function key
- custom print string for connecting to label printer
- clock/date, counting, peak hold, manual hold total functions
- RS232 output module for serial communication
- includes stainless steel wall / pole mounting bracket and backshell as standard (as depicted)
- can also be panel mounted
OPTIONS
- optional ABS desk stand with 4 AA batteries
optional OptoLink data cable for data extraction available on request (part # RIA10012)
| Legal For Trade Use | Yes when connected to an approved scale base |
| MCA# | 1736 |
| Max Approved Divisions |
4,000 d per range. |
| Max Divisions (Non-Approved) | 30,000 |
| Number of Ranges | Single or dual interval |
| Minimum Sensitivity per Division | 0.8µV/d |
| Main Display Size | 20 mm |
| Second Display Size | NA |
| Backlight | Yes - green |
| Mounting Options | Wall bracket optional |
| Inputs / Outputs | 2 Outputs |
| Setpoints | Yes |
| Communication Protocol | RS232 |
| Built-in Printer | No |
| Counting Function | Yes |
| Check Weighing Function | Yes |
| Environment Suitability | Dry |
| Ingress Protection Rating | IP65 |
| Power Source | 230V AC or 7-24V DC |
| Battery Option | Rechargeable battery option (order code RIR310K) |
| Overall Dimensions (mm) | 164 (W) x 97 (D) x 77 (H) |
Digital Scale Indicator ENQUIRE NOW BUY NOW
RIR300
A robust Digital Scale Indicator with superior quality IP65 ABS plastic housing. It includes RS232 output designed for direct connection to PLC’s, PC’s or thermal label printers. The large easy to read high contrast LCD display features a LED backlight along with a protective lense to reduce risk of damage. Can be customised for use in forklift, truck weighing, agricultural processing, pallet jack weighing, crane scales & packaging applications. It is also Legal for Trade Use when used with approved scale bases.
FEATURES AND SPECIFICATIONS
Price of Selection (NZ$ excl GST)
POA
Variations
Digital Scale Indicator
Minimum Sensitivity / Division: 0.8µV/d
Max Approved Divisions: 4000 per range
Overall Dimensions (mm): 164 (W) x 97 (D) x 77 (H)
POA
